Preamplifier section

Input impedance ( Balanced input )  47Kohm

Maximum input level  10 Volt RMS

Noise floor ( 1Vrms, 20 - 20 kHz, balanced)  -135 dB

THD + N   (1Vrms, 20 - 20 kHz, balanced)   <0.004%

Gain (Balanced)  0 dB

Amplifier section

Output Impedance < 0,02 Ohm

Frequency response 1 – 150 kHz

Channel separation > 120 dB

THD ( 20 - 20 kHz) < 0.004%

Maximum peak current >100A

Damping factor  8 ohm load >350

I Input sensitivity  120W output 1.3Vrms

Input sensitivity HT  120W output 1Vrms

Gain HT Input x36 (31 dB)

Rated output power

8 ohms  2 x 125 W

4 ohms  2 x 200 W

2 ohms  2 x 370 W

Power consumption  110 W

Standby 1W

(no load or signal)

Dimensions

Width 470 mm / 18.3 inches

Depth ( with a speaker terminals) 430 mm / 16.9 inches

Height 128 mm / 5 inches

Weight 20.5 Kg / 45 lbs.
