FEATURES

• Works with all line drive preamplifiers
• RIAA curve accurate to 0.25 dB
• Ultra-low distortion
• Switchable gain for moving magnet or moving coil cartridges
• Exclusive AC polarity switch to eliminate hum
• Ultra high-speed, low-noise opamps
• Audiophile grade resistors and capacitors
• Gold-plated RCA input and output jacks
• Unique half-rack width chassis; 1 rack space high
• Rack mount kit sold separately (click to view)



  SPECS




  Gain at 1 kHz :
  MM, 46dB; MC, 61 dB

  Input Sensitivity at 1 kHz :
  MM, 5 mV in for 1.1 V output
  MC, .9 mV in for 1.1 V output

  Input Impedance :
  MM, 47 k Ω
  MC, 100 Ω

  Input overload:
  MM, 200 mV; MC, 36 mV

  RIAA accuracy:
  0.25 dB, 20 Hz - 20 kHz

  S/N ratio:
  MM, 84 dB
  MC, 58 dB

  Power requirement:
  115 V - 230 V, 60/50 Hz, 5 W

  Dimensions:
  8-1/2 w x 1-3/4 h x 10 d, 2 h with feet

  Net weight: 4 lbs.
