★Musical Fidelity(뮤지컬피델리티)★ M6CD CD플레이어 매장전시품!!!
작성자: 킹사운드
02-3424-4425 02-3424-4426 master＠kingsound.co.kr
2016-10-12
조회 1154
IP 59.6.*.*
★Musical Fidelity(뮤지컬피델리티)★ M6CD CD플레이어 매장전시품!!!
뮤지컬피델리티 M6CD CD플레이어 입니다.매장전시품 저렴한 가격으로 판매합니다.
박스분실했으며, 리모콘만 있습니다.
감사합니다.
.jpg)
.jpg)
.jpg)
| 뮤지컬피델리티 M6CD 제품정보 |
Output |
|
| Output impedance |
50 ohms balanced or single ended |
| Output, digital 0dB level | XLR output - 4.4V r.m.s. balanced nominal |
| RCA output - 2.2V r.m.s. single ended nominal | |
DAC (balanced and single-ended outputs) |
|
| DAC circuit | 24 bit Delta-Sigma (bit stream) dual differential 8x over-sampling |
| Total correlated jitter | <135 picoseconds peak to peak |
| Frequency response | <0.1dB down to -96dB |
| Frequency response | 10Hz to 20 kHz -0.2dB max. |
| Channel separation | >105dB 20 Hz to 20 kHz |
| Signal-to-noise ratio | >117dB “a”- wtd. |
| Total harmonic distortion | <0.003% 10Hz to 20 kHz |
Connections |
|
| Line level outputs | 1 pair line level RCA connectors, left and right outputs 1 pair line level XLR connectors, left and right outputs |
| Digital outputs | 1 RCA coaxial connector SPDIF 1 TOSLINK optical connector |
| Digital inputs | 1 RCA coaxial connector SPDIF 1 TOSLINK optical connector |
| USB input | USB type “B” (square) socket |
Power requirement |
|
| Mains voltages | 115/230VAC 50/60Hz (factory pre-set) 100VAC 50/60Hz (alternative) |
| Consumption | 20 Watts maximum |
Weight |
|
| Unit only, unboxed | 11.2 kg (24⅔ lbs) |
| In shipping carton | 15.5 kg (34 lbs) |
Dimensions |
|
| Wide | 440 mm (17⅓”) |
| High, including feet | 125 mm (5”) |
| Deep (front to back) including terminals | 385 mm (15⅛”) |
Standard accessories |
|
| IEC type mains lead (10-Amp type) | |
| M6 remote control | |
|
